LHF-606H

Download
  • Masteel Fabrication Catalogue
Series Image

3-Roll Plate Bending Rolls A universal machine for all plate bending jobs, and especially for the job-shop fabricator. The 3-roll, double pinch design which provides excellent pre-bending capabilities; it is easy to pre-bend both the leading and trailing edge without the need to remove, turn, and re-insert the plate. The quality of a profile rolled on this machine will be the same to ones rolled on 4-roll double pinch or 3-roll initial-pinch machines. The two lower rolls can be adjusted individually of each other, with infinitely variable adjustment speeds, in a curved path around a common center. The standard rolls are manufactured of SF45C solid steel forgings with carbon 0.38 ~ 0.45% and go thru high frequency heat treatment on surface at HRC45 or above for maximum surface hardness. Especially on the top roll, it comes with cambering design for compensating during rolling. Furthermore, all rolls are equipped with self-aligning and lubricating bearings. A single hydraulic motor with a reducer and chains drives all three rolls, allowing any one, two, or all three rolls to provide 100% driving torque at all times. This drive system is easy to maintain, and also the most effective system for drive torque. This type of machine is most suitable to do jobs from 6mm to 75 mm thickness, with 2000 mm to 6000mm width.

Request Quote on This Model

Select Machine Size/Model Here

Specifications

MODEL LHF-606H
PRE-BENDING (MM) 6 x 2000
BENDING (MM) 9 x 2000
ROLL DIA. (MM) 210
MOTOR (HP) 7.5
WEIGHT (KG) 4100
L x W x H (MM) 4013 x 1016 x 1321
Request Quote on This Model
