VL-1000ATC
Heavy Duty Vertical Lathes
• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.
Request Quote on This Model
Select Machine Size/Model Here
Specifications
| Model | Unit | VL-1000ATC |
| Max. Swing Dia. | mm | Ø1350 |
| Max. Turning Dia. | mm | Ø1150 |
| Max. Turning Height | mm | 1070 |
| Main Spindle Motor | kw | 37/45 |
| Machine (L1) | mm | 4600 |
| Machine (W1) | mm | 5500 |
| Machine (H1) | mm | 5330 |
| Machine Weight | kg | 24000 |
