LTC-20B
Horizontal / Heavy Duty
Request Quote on This Model
Select Machine Size/Model Here
Technical Specifications
| MODEL | LTC-20B | |
| Max. swing | mm(in) | 450 (17.7) |
| Max. turning diameter | mm(in) | 320 (12.6) |
| Max. turning length | mm(in) | 500 (19.6) |
| Bar capacity | mm(in) | 65 (2.6) |
| X axis travel | mm(in) | 160+10 (6.2+0.39) |
| Z axis travel | mm(in) | 540 (21) |
| Spindle speed | rpm | 4000 |
| Chuck size | mm(in) | 203(8) |
| Spindle nose | A2-6 | |
| Number of tool stations | pcs | 8 |
| Shank height for square tool | mm(in) | 25(1) |
| Shank diameter of boring bar | mm(in) | 40 (1.5) |
| X/Z axis rapid traverse | m/min(ipm) | 20/20 (787.4/787.4) |
| X axis motor | kw(hp) | 1.8 (2.4) |
| Z axis motor | kw (hp) | 1.8 (2.4) |
| Machine size (LxWxH) | mm | 2665x1590x1590 |
| Machine weight | kg | 3700 |
