LCV-760
Travel Column APC / High Production
Request Quote on This Model
Select Machine Size/Model Here
Technical Specifications
| MODEL | LCV-760 | |
| X axis travel | mm(in) | 760 (29.9) |
| Y axis travel | mm(in) | 610 (24) |
| Z axis travel | mm(in) | 610 (24) |
| Table size (L x W) | mm(in) | 850x600 (33.4x23.6) |
| Max. table load | kg | 800 fix / 500 turn |
| Spindle speed | rpm | 10000 |
| Rapid traverse X/Y/Z | m/min/(ipm) | 32/32/28 (1259/1259/1102) |
| Tool storage capacity | pcs | 30 |
| A.P.C number of pallets | pcs | 2 |
| Spindle motor (30min) FANUC | kW (hp) | 18.5 (24.8) |
| X/Y/Z axis feed motors | kW (hp) | 7/4/4 (9/5.4/5.4) |
| Machine size (L x W x H) | mm | 3320x4800x2980 |
| Machine weight | kg | 10500 |
