HSM-600
HIGH SPEED MILLING
Request Quote on This Model
Select Machine Size/Model Here
Specifications
| MODEL | HSM-600 |
| TABLE: | |
| OVERALL SIZE | 850×400 |
| T SLOTS (SIZE×NO×PITCH) | 14×3×125 |
| MAXIMUM LOAD | 350KG |
| TRAVEL: | |
| X / Y / Z AXIS | 600 / 430 / 460 |
| 3 AXIS LINEAR WAY | |
| LINEAR WAY WIDTH | 30 / 30 / 35 |
| LINEAR WAY NUMBER | 2 on each axis |
| DISTANCES: | |
| SPINDLE TO COLUMN WAYS | 480 |
| SPINDLE TO TABLE TOP | 120~580 |
| FLOOR TO TABLE TOP | 852 |
| SPINDLE: | |
| TAPER | #40 |
| SPEED | 8000RPM |
| FRONT BEARING DIA. | 60 |
| MOTOR | 5.5 / 7.5KW |
| AXIS MOTORS : | |
| AXIS MOTOR TORQUE | 8 / 8 / 12Nm |
| MOTOR POWER | 1.6 / 1.6 / 3KW |
| Z AXIS BALANCE DESIGN | BRAKING MOTOR |
| CUTTING FEED RATE | 1-8000MM / Min |
| RAPID FEED RATE | 30M / 30M / 24M |
| MINMUM SETTING | 0.001MM |
| ATC: | |
| TYPE | SWING ARM |
| NO. OF TOOLS | 20 |
| MAX. TOOL (DIA / LENGTH) | 125 / 250 |
| MAX. TOOL WEIGHT | 7KG |
| TOOL TO TOOL/CHIP TO CHIP | 3” / 8” |
| BALLSCREWS: | |
| DIA / PITCH ( X&Y AXIS ) | 32×16 |
| DIA / PITCH ( Z AXIS ) | 32×16 |
| PRECISION CLASS (C3) | 0.08MM / 300MM |
| COOLANT & LUBR: | |
| COOLANT MOTOR POWER | 1.27KW |
| COOLANT TANK VOLUME | 120L |
| COOLANT MOTOR CAPACITY | 20L / MIN |
| LUBE MOTOR POWER | 25 WATT |
| LUBE TANK VOUME | 2 |
| ACCURACY: | |
| POSITIONING | JIS 6338 : 0.005MM / 300MM, VDI 3441 : P0.015 |
| REPEATABILITY | JIS 6338 : ±0.003MM, VDI 3441 : PS0.01 |
| ROUNDNESS | JIS 6338 : ±0.01MM / 300MM DIAMETER |
| MISCELLANEOUS: | |
| NET WEIGHT | 3400KG |
| POWER REQUIRED | 16KVA |
| PNEUMATIC REQUIRED | 7KG / CM2 |
