UDM-2217E

STANDARD ACCESSORIES
Glass window type splash guard
Programmable coolant system
Automatic lubrication system
Spindle air blast system
Working lamp
Alarm lamp for abnormal situations
Indication lamp for dwell & end of job
Leveling bolts & pads
Chip auger & chain type chip conveyors
Toolbox with spanners & wrenches
M.P.G
Machine inspection lists
Operation manuals
Controller manuals and circuit diagram
Auto power off
RS-232C terminal interface
Spindle coolant system
Hydraulic system
Heat exchanger
FAGOR Controller

Request Quote on This Model

Select Machine Size/Model Here

UDM-2217E

Technical Specifications

MODEL UNIT UDM-2217E
TABLE Table Size mm 2000x1500
T-Slots mm 22
Maximum Load tons 6
TRAVEL X Axis mm 2200
Y Axis mm 1700
Z Axis mm 1000
SPINDLE Spindle Servo Motor-cont./ 30min. kW 15/18.5 (22/26)
Speed rpm 4000(6000)
Taper   7/24 taper ISO.50, BT-50
DISTANCES Between Two Columns mm 1800
Spindle Nose to Table Center mm 200~1200
FEED RATE Rapid Feed rate X/Y/Z m/min. 15/15/12
Minimum Setting mm/min. 0.001
Cutting Feed rate mm/min. 1~8000
COOLANT & LUBRICATION Coolant Tank Volume L 450
Hydraulic Tank Volume L 70
Lubrication Tank Volume L 8
MISCELLANEOUS Power Required kVA 50
Pressurized Air kg/cm² 7
Hydraulics Required kg/cm² 70
Machine Weight tons 22
Controller   FANUC 0iMF (FANUC 32i-MB/ 31i-MB / MELDAS / SIEMENS / HEIDENHAIN)
