Standard Features: Shuttle Type Automatic Feed 3pcs Carbide blade guide system Present cut-counter with shut-off Power Driven Blade Brush Nesting fixture for bundle cutting Infinitely variable speed controlled by inverter Hydraulic Blade Tension PLC control for all electronic and Hydraulic functions Work light Automatic Chipping Conveyor Lead Screw LED Display of Blade Speed Check Device of Saw Blade Breaking Flushing Hose for Machine Cleaning Multiple Index (9 times) Automatic Work Height Control and Fast Approach Split Front Vise Floating Shuttle Vise 2 M Roller Table One Bi-Metal Saw Blade Tool Box
Capacity | |
Round Bar | Dia. 550mm |
Square Bar | 550x550mm |
Blade size | 5980x41xT 1.3mm |
Blade Speed | 20-100m/min. inverter |
Voltage | 415V |
Weight | 2500kg |
Blade Motor | 7PH 3HP |
Hydraulic Pump | 2HP |
Coolant Pump | 1/4 HP |
NC Control System
Full Stroke – Hydraulic
Clamping Vise
