LCH-500
FEATURES Fagor 8060 control Chip conveyor inside machine(auger type) Chip conveyor outside machine & chip bucket 12000RPM with 2 speed spindle motor CTS 20 bar-300PSI through spindle coolant Arm ATC with 40 tools magazine 500x500mm twin pallet Rotary table 0.001° Fully enclosed guarding Oil skimmer CAT 40 spindle Tool tip air blow system Remote MPG Spindle oil cooler Rigid tapping Metric table Shower coolant Heat exchanger
Request Quote on This Model
SPECIFICATIONS
| X axis travel | mm(in) | 700 (27.5) |
| Y axis travel | mm(in) | 610 (24) |
| Z axis travel | mm(in) | 610 (24) |
| Table size (L x W) | mm(in) | 500x500 (19.6x19.6) |
| Max. table load | kg | 500 |
| Spindle speed | rpm | 12000 |
| Rapid traverse X/Y/Z | m/min/(ipm) | 32/28/32 (1259/1102/1259) |
| Tool storage capacity | pcs | 40 |
| A.P.C number of pallets | pcs | 2 |
| Spindle motor (30min) FANUC | kW (hp) | 18.5 (24.8) |
| X/Y/Z axis feed motors | kW (hp) | 7/4/4 (9/5.4/5.4) |
| Machine size (L x W x H) | mm | 3320x3800x2980 |
| Machine weight | kg | 11500 |
...
